pH - Oxidation Reduction Potential electrodes PH-ORP Series

      Download files

      User manual Series PH-ORP (Esp)

      User manual Series pH-ORP bi-channel (Esp) (IN PROGRESS)



      In the PH-ORP series you can find several sensors for different measurement ranges, constructed with different materials and different electrode geometry  (flat, hemispherical, hemispherical with cage) making them suitable for a wide range of process.



      Models and characteristics for pH meters of the PH-ORP series

      pH sensors models
      Model LA-PH-G-M-PW-T2-005
      		LA-PH-P-M-PW-T1-005
      		LA-PH-G-M-W-T3-005
      		LA-PH-P-M-W-T1-005
      Measurement range
      		 0.00-14.00 PH
      		0.00-14.00 PH
      		0.00-14.00 PH
      		 2.00-12.00 PH
      Medium Sewage water, RO system, pool water, cooling tower, agricultura, hydroponic, drinking water.
      		 Pure Water
      		 Sewage water, RO system, pool water.
      		 Desulfurization and denitrification, Waste water treatment
      Body material Glass
      		 ABS
      		  Glass
      		 Plastic
      Temperature range 0-100°C
      		0-60°C
      		0-130°C
      		0-60°C
      Connections 3/4'' NPT
      		3/4'' NPT
      		3/4'' NPT
      		3/4'' NPT
      Electrode Hemispherical
      		  Hemispherical with cage
      		 Hemispherical
      		 Flat
      Pressure
      		 6 Bar 4 Bar 2.5 Bar  2 Bar

      Models and characteristics for ORP meters of the PH-ORP series

      ORP sensors models
      Model LA-ORP-G-M-PW-T2-005  LA-ORP-P-M-W-T1-005
      Measurement range
      		 -2000 ~ 2000 mV
      		-2000 ~ 2000 mV
      Medium Aguas residuales, sistema RO, piscina, torre de refrigeración, agricultura, hidropónico, agua potable
      		Aguas residuales, sistema RO, piscina, torre de refrigeración, agricultura, hidropónico, agua potable
      Body material vidrio
      		plástico
      Temperature range 0-100°C
      		0-60°C
      Connections 3/4'' NPT
      		3/4'' NPT
      Ingress protection rating IP68 IP68
      Pressure
      		 6 Bar
      		6 Bar

      Gallery

      Datos técnicos

       One channel pH and ORP meter

      • pH range: 0.00-14.00 PH
      • ORP Range: -999 ~ 999
      • Automatic temperature compensation
      • Temperature range -10 a 130°C. Precision <0.5°C
      • Resolution: 0.01PH & 1mV
      • Precision: 0.02PH & 5mV
      • Analog output 4-20 mA
      • Communication: MODBUS RS-485
      • Ingress protection rating: IP57
      • Power supply: 24 VDC.


      Two channel pH and ORP meter

      • pH range: 0.00-14.00 PH
      • ORP range: -1999 ~ 1999
      • Automatic temperature compensation
      • Free chlorine estimation
      • Temperature range -10 a 130°C. Precision <0.5°C
      • Resolution: 0.01PH & 1mV
      • Precision: 0.02PH & 5mV
      • Analog output 4-20 mA
      • Communication: MODBUS RS-485
      • Ingress protection rating: IP57
      • Power supply: 24 VDC.



      Common applications

       Industrial pH and ORP meters are applied in the chemical, metallurgical, pharmaceutical and food industries also in mining, environmental protection, agriculture, etc. The computer has a 4-20mA analog signal, RS-485 digital signal and relay outputs. It can be used for industrial processes and water treatment processes, pH control, remote data transmission, etc.
